12-40W 可控硅调光电源
产品特性：
输入电压：200-240VAC
输出功率：40W
安全标准：EN61347
适用于LED照明
质保：3年
高PF
隔离设计
高可靠性
自然风冷
|
Model
型号
|
Power
(Max.)
最大功率 |
I/P Voltage
输入电压
|
O/P Voltage
输出电压
|
O/P Voltage
输出电流
|
Current Tolerance
电流精度
|
Typ.PF
功率因素
|
Efficiency
效率
|
Dimension
尺寸
|
| XT-GS012A-WA0300 | 12W | 200-240VAC | 24-40V | 300mA | ±5% | ≥0.9 | 84% | L 103*W67*H30mm |
| XT-GS012A-WB0240 | 12W | 200-240VAC | 36-50V | 240mA | ±5% | ≥0.9 | 84% | L 103*W67*H30mm |
| XT-GS020A-WA0400 | 20W | 200-240VAC | 36-50V | 400mA | ±5% | ≥0.9 | 85% | L 103*W67*H30mm |
| XT-GS020A-WB0500 | 20W | 200-240VAC | 27-40V | 500mA | ±5% | ≥0.9 | 85% | L 103*W67*H30mm |
| XT-GS030A-WA0600 | 30W | 200-240VAC | 36-50V | 600mA | ±5% | ≥0.9 | 86% | L 103*W67*H30mm |
| XT-GS030A-WB0750 | 30W | 200-240VAC | 27-40V | 750mA | ±5% | ≥0.9 | 86% | L 103*W67*H30mm |
| XT-GS030A-WC1000 | 30W | 200-240VAC | 20-30V | 1000mA | ±5% | ≥0.9 | 86% | L 103*W67*H30mm |
| XT-GS040A-WA0700 | 40W | 200-240VAC | 36-50V | 700mA | ±5% | ≥0.9 | 86% | L 103*W67*H30mm |
| XT-GS040A-WB1000 | 40W | 200-240VAC | 27-40V | 1000mA | ±5% | ≥0.9 | 86% | L 103*W67*H30mm |
| XT-GS040A-WC1300 | 40W | 200-240VAC | 20-30V | 1300mA | ±5% | ≥0.9 | 86% | L 103*W67*H30mm |
